Product Overview
The SPM-ERT2X-PXX is a 10/100/1000 Ethernet Mini media converter that provides cost-effective entry-level media conversion between 10/100/1000Base-T ports and 10/100/1000Base-X ports. With its fixed configuration, deployments are just plug-and-play, and the hot-swappable dual-speed SFP port supports auto-sensing 10M/100M or 1000M SFP transceivers. A wide variety of SFP optical transceivers are available to offer a full range of deployment options over multimode or single-mode fiber. This Mini converter is an ideal solution for fiber integration in both Fast Ethernet and Gigabit Ethernet environments, and along with its small size, it is perfect for locations where space is limited.
Features
- Unit & Port LEDs allow for quick status information
- Auto-Negotiation
- Fixed Full-Duplex on Fiber
- Auto-MDI/MDIX
- LFP (Link Fault Pass-through) support
- Jumbo Frame (up to 10240 Bytes)
- DIP switch to set different configuration
Specifications
| Parameter | Specification |
|---|---|
| Converter Type | Mini media converter |
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, 100Base-FX |
| Data Rate | 10/100/1000M |
| Port Type | 1×RJ45 to 1×SFP |
| Status LEDs | PWR (Power) below RJ-45: On=Power FX-Link/Act (Fiber Link/Activity) Upper Left on RJ-45: On=link Flashing=Activity TX-Link/Act (Copper Link/Activity) Upper Right on RJ-45: On=link Flashing=Activity |
| Dimensions | 60mm(W)×20mm(H)×90mm(L) |
| Packing Dimensions | 84mm(W)×70mm(H)×135mm(L) |
| Case Material | Iron |
| Transmission Distance | Multi-mode: 2km Single-mode: 20/40/60/80/100km Cat-5 twisted pairs: 100m |
| Power Consumption | <3W |
| Power Supply | External AC/DC required; +12VDC 0.5A |
| Cooling | Free air convection |
| Conversion Means | Store and Forward mode or Cut-Through mode |
| Flow Control | Full duplex: flow control Half duplex: backpressure |
| Environment | Operating: 0°C to 50°C Storage: -15°C to 65°C Humidity: 5% to 95% (non-condensing) Altitude: 0-10000ft |
| Maintaining Temperature | -40~70°C |
| Weight | 0.15kg |
Ordering Information
| Part Number | Product Description | Remark |
|---|---|---|
| SPM-ERT2X-PXX | Mini 1-Port 10/100/1000Base-TX to 10/100/1000Base-FX SFP Slot Media Converter |
