Product Overview
The SPM-E_1X_T2X-PXT is a 10/100/1000Mbps industrial fiber switch with operating temperature from -40°C to +85°C, supporting wide voltage dual power input, meeting IP40 protection degree and EMC industrial grade requirements, DIN rail installation, passing hazardous environment certification and complying with FCC and CE standards. The reliable industrial grade design ensures continuous and stable operation of the automation system.
Key Features
- 1~8× 10/100/1000Mbps Auto-sensing RJ45 ports
- 1×1000Mbps SFP port
- 4KV Ethernet surge protection for harsh outdoor environment
- Support Auto MDI/MDIX
- Flow control: full duplex IEEE 802.3x standard, half duplex Back pressure standard
- IEEE 802.3 10Base-T and IEEE 802.3u 1000Base-TX compliant
- Store-and-forward switching mechanism
- Operating temperature: -40°C ~ 85°C
Specifications
| Item | Specification |
|---|---|
| Product Name | 10/100/1000Mbps Industrial Fiber Switch (1 Fiber to X UTP) |
| Model No. | SPM-E_1X_T2X-PXT |
| Optical Port | 1×1000Mbps SFP port |
| Optical Transmission Distance | SM: 1310nm/1550nm, 20Km; 1490nm/1550nm, 40~120Km; MM: 1310nm, 2Km |
| Electrical Port | 1~8 × 10/100/1000M UTP RJ45 (Support MDI/MDIX auto-sensing) |
| Switching Features - Transmission Mode | Store-and-forward |
| System Bandwidth | 1SFP+1UTP: 4Gbps; 1SFP+2UTPs: 6Gbps; 1SFP+4UTPs: 10Gbps; 1SFP+6UTPs: 14Gbps; 1SFP+8UTPs: 18Gbps (non-traffic jam) |
| Network Media | 10BASE-T: CAT3/CAT4/CAT5 unshielded twisted pair (≤100m); 100BASE-TX: CAT5 or above shielded twisted pair (≤100m); SFP port, transmission distance: 20Km/40Km/60Km/80Km/100Km |
| LEDs | Power/network/fiber |
| Power Supply Input | DC 9-52V |
| No-load Power | 5W |
| Reverse Connection | Support |
| Working Temperature | -40°C ~ 85°C |
| Storage Temperature | -40°C ~ 85°C |
| Working Humidity | 10%～90%, non-condensing |
| Storage Humidity | 10%～95%, non-condensing |
| EMI Standards | FCC Part 15 Subpart B Class A, EN 55022 Class A |
| EMS Standards | EN61000-4-2 (ESD) Level 3, EN61000-4-3 (RS) Level 3, EN61000-4-4 (EFT) Level 3, EN61000-4-5 (Surge) Level 3, EN61000-4-6 (CS) Level 3, EN61000-4-8 |
| Traffic Control | NEMA-TS2 |
| Vibration | IEC 60068-2-6 |
| Free Fall | IEC 60068-2-32 |
| Shock | IEC 60068-2-27 |
| Rail Traffic | EN50121-4 |
| Safety | CE Mark commercial, CE/LVD EN60950 |
| Shell | Corrugated metal shell |
| Protection Class | IP40 |
| Dimension | 114x94x35.5mm (1~4×10/100/1000M UTP RJ45); 158x114.8x60mm (6~8×10/100/1000M UTP RJ45) |
| Mounting Method | Din-rail mounting |
| Warranty | Replacement within 1 year; 5 years repairing |
Ordering Information
| Part Number | Product Description |
|---|---|
| GigabitIndustrial MediaConverter 1*10/100/1000Base-Tx to 1*SFP | SPM-ET2X-PXT |
| slotwithout SFPmodules | GigabitIndustrial MediaConverter 2*10/100/1000Base-Tx to 1*SFP |
| SPM-E12T2X-PXT | slotwithout SFPmodules |
| GigabitIndustrial MediaConverter 4*10/100/1000Base-Tx to 1*SFP | SPM-E14T2X-PXT |
| slotwithout SFPmodules | GigabitIndustrial MediaConverter 6*10/100/1000Base-Tx to 1*SFP |
| SPM-E16T2X-PXT | slotwithout SFPmodules |
| GigabitIndustrial MediaConverter 8*10/100/1000Base-Tx to 1*SFP | SPM-E18T2X-PXT |
